50×50×2.5 SHS Weight, Dimensions and IS 4923 Properties
50×50×2.5 SHS weighs 3.65 kg per metre as per IS 4923:1997.
- One 6-metre length weighs 21.9 kg · one 12-metre length weighs 43.8 kg
- 50 × 50 mm square section · wall thickness 2.5 mm
- Cross-sectional area 4.65 cm² · Ixx = 12.6 cm⁴
50×50×2.5 SHS is a standard square hollow section manufactured to IS 4923:1997 by APL Apollo YST 310. At 3.65 kg/m it is used for carport canopy and similar structural applications where a square hollow profile with defined sectional properties is required.
50×50×2.5 SHS Weight Calculator
Enter the total length in metres to calculate weight.
50×50×2.5 SHS — Weight Calculator
IS 4923:1997 Dimensions and Sectional Properties
| Property | Symbol | Unit | Value |
|---|---|---|---|
| Outside dimension | B | mm | 50 |
| Wall thickness | t | mm | 2.5 |
| Cross-sectional area | A | cm² | 4.65 |
| Mass per metre | — | kg/m | 3.65 |
| Moment of inertia | Ixx = Iyy | cm⁴ | 12.6 |
| Elastic section modulus | Zxx = Zyy | cm³ | 5.04 |
| Radius of gyration | rxx = ryy | cm | 1.65 |
Outside dimensions and wall thickness as per IS 4923:1997. Cross-sectional area and mass per metre from IS 4923:1997 Table 2. Sectional properties calculated from IS 4923 geometry. SHS is doubly symmetric — Ixx = Iyy, Zxx = Zyy, rxx = ryy. Mass tolerance: ±6% per individual piece as per IS 4923:1997 Clause 10.
Common Applications of 50×50×2.5 SHS
50×50×2.5 SHS is used in carport canopy and related structural framing. The square hollow profile provides equal stiffness about both axes, making it well suited for columns, posts, and members loaded in biaxial bending. APL Apollo YST 310 supply this section in YST 310 and YST 355 grade to IS 4923:1997 from stock at major steel distributors across India.
Worked Example
A fabricator in Surat needs 6 canopy posts of 50×50×2.5 SHS, each 4.5 m long, for a carport canopy. Total length = 6 × 4.5 = 27.0 m. Weight = 27.0 × 3.65 = 98.5 kg. At a market rate of ₹65,000 per tonne (May 2026), material cost is approximately ₹6,406 before cutting and fabrication.
Related IS 4923 Sections
Previous smaller: 40×40×2.5 SHS (2.87 kg/m) · Next larger: 60×60×3 SHS (5.28 kg/m). For all hollow sections see the Section Reference Library →
Frequently Asked Questions
What is the weight of 50×50×2.5 SHS per metre?
50×50×2.5 SHS weighs 3.65 kg per metre as per IS 4923:1997. For a standard 6-metre length, the total weight is 21.9 kg. For a 12-metre length, total weight is 43.8 kg.
50×50×2.5 square hollow section ka weight kitna hota hai?
IS 4923:1997 ke according, 50×50×2.5 square hollow section ka weight 3.65 kg/m hota hai. 6 metre ki ek length ka total weight 21.9 kg hoga. Zyada accurate calculation ke liye upar diya gaya calculator use karein.
What are the dimensions and wall thickness of 50×50×2.5 SHS?
50×50×2.5 SHS per IS 4923:1997 has an outside dimension of 50 × 50 mm and a wall thickness of 2.5 mm. The cross-sectional area is 4.65 cm². Mass tolerance is ±6% per piece as per IS 4923:1997 Clause 10.
