ISHB 225 Weight, Dimensions and IS 808 Properties
ISHB 225 weighs 49.3 kg per metre as per IS 808:1989.
- One 6-metre length weighs 295.8 kg · one 12-metre length weighs 591.6 kg
- Overall depth 225 mm · flange width 225 mm · web thickness 6.5 mm
- Cross-sectional area 6,376 mm² · Ixx = 5,959.0 cm⁴
ISHB 225 is a medium-heavy column section in IS 808:1989. At 49.3 kg/m with equal depth and flange width of 225 mm, it sits between the popular ISHB 200 and ISHB 250 sizes. The equal 225 × 225 mm wide-flange profile gives high biaxial stiffness, suited to medium-height columns in industrial frames where both strong- and weak-axis loads are significant.
ISHB 225 Weight Calculator
Enter the total length in metres to calculate weight.
ISHB 225 — Weight Calculator
IS 808:1989 Dimensions and Sectional Properties
| Property | Symbol | Unit | Value |
|---|---|---|---|
| Overall depth | D | mm | 225 |
| Flange width | B | mm | 225 |
| Web thickness | tw | mm | 6.5 |
| Flange thickness | tf | mm | 9.9 |
| Cross-sectional area | A | mm² | 6,376 |
| Mass per metre | — | kg/m | 49.3 |
| Moment of inertia (x–x) | Ixx | cm⁴ | 5,959.0 |
| Moment of inertia (y–y) | Iyy | cm⁴ | 1,553.0 |
| Elastic section modulus (x–x) | Zxx | cm³ | 529.7 |
| Elastic section modulus (y–y) | Zyy | cm³ | 138.0 |
| Radius of gyration (x–x) | rxx | cm | 9.67 |
| Radius of gyration (y–y) | ryy | cm | 4.93 |
Dimensions and properties as per IS 808:1989 (reaffirmed 2021). Mass tolerance: ±2.5% per piece per IS 808.
Common Applications of ISHB 225
ISHB 225 is used for primary columns in medium industrial structures up to 7 m height, column sections in portal frame buildings with moderate loads, and members in heavy mezzanine floor structures. Its equal 225 × 225 mm cross-section provides near-balanced r_xx and r_yy values — useful for columns loaded in two planes simultaneously. Note that ISHB 225 is less commonly stocked than ISHB 200 and ISHB 250; always verify lead time with your stockist before specifying. SAIL Bhilai supplies ISHB 225 in IS 2062 E250 and E350 grade, typically on indent.
Worked Example
A structural engineer in Pune specifies 14 columns of ISHB 225, each 6 m tall, for a medium industrial storage building. Total length = 14 × 6 = 84 m. Weight = 84 × 49.3 = 4,141.2 kg (4.141 tonnes). At a market rate of ₹63,000 per tonne (Pune, May 2026), the material cost is approximately ₹2,60,900 before base plates, cap plates, and erection.
Related ISHB Sections
Compare with adjacent sizes: ISHB 200 (40.0 kg/m) · ISHB 250 (54.7 kg/m). For all ISHB sizes see the Section Reference Library →
Frequently Asked Questions
What is the weight of ISHB 225 per metre?
ISHB 225 weighs 49.3 kg per metre as specified in IS 808:1989. For a standard 6-metre length, the total weight is 295.8 kg. For a 12-metre length, total weight is 591.6 kg.
ISHB 225 ka weight per meter kitna hota hai?
IS 808:1989 standard ke according, ISHB 225 ka weight 49.3 kg/m hota hai. 6 metre ki ek length ka total weight 295.8 kg hoga. Zyada accurate calculation ke liye upar diya gaya calculator use karein.
What are the dimensions of ISHB 225?
ISHB 225 per IS 808:1989 has an overall depth of 225 mm, flange width of 225 mm, web thickness of 6.5 mm, and flange thickness of 9.9 mm. The cross-sectional area is 6,376 mm².
