ISA 110×110×10 Weight, Dimensions and IS 808 Properties
ISA 110×110×10 weighs 16.5 kg per metre as per IS 808:1989.
- One 6-metre length weighs 99.0 kg · one 12-metre length weighs 198.0 kg
- Leg 110 mm × thickness 10 mm · root radius 12.0 mm
- Cross-sectional area 20.99 cm² · Iuu = 217.0 cm⁴
ISA 110×110×10 is a heavy structural equal-leg angle in IS 808:1989. At 16.5 kg/m with a 110 mm leg it is used for primary chord members in large-span trusses, back-to-back compound column sections, and heavy primary bracing in large industrial and infrastructure structures.
ISA 110×110×10 Weight Calculator
Enter the total length in metres to calculate weight.
ISA 110×110×10 — Weight Calculator
IS 808:1989 Dimensions and Sectional Properties
| Property | Symbol | Unit | Value |
|---|---|---|---|
| Leg length | A | mm | 110 |
| Thickness | t | mm | 10 |
| Root radius | r1 | mm | 12.0 |
| Cross-sectional area | A | cm² | 20.99 |
| Mass per metre | — | kg/m | 16.5 |
| Centroid distance (Cxx = Cyy) | Cxx | cm | 2.67 |
| Moment of inertia (u–u, max) | Iuu | cm⁴ | 217.0 |
| Moment of inertia (v–v, min) | Ivv | cm⁴ | 56.38 |
| Elastic section modulus (u–u) | Zuu | cm³ | 28.04 |
| Radius of gyration (u–u) | ruu | cm | 3.21 |
| Radius of gyration (v–v) | rvv | cm | 1.64 |
Dimensions and properties as per IS 808:1989 (Reaffirmed 2001). Mass tolerance: ±3% per piece as per IS 808. u–u is the major principal axis at 45° to both legs; v–v is the minor principal axis. Zvv is not published in IS 808:1989 for angle sections.
Common Applications of ISA 110×110×10
ISA 110×110×10 is used for primary truss chord members in 22–28 m span structures, back-to-back built-up compound columns, heavy primary wind bracing members, and large bolted gusset plate connections. Stocked by JSPL, Tata Steel, and SAIL in IS 2062 E250 grade.
Worked Example
A structural engineer in Ahmedabad specifies ISA 110×110×10 for 10 bottom chord members, each 6 m long, for a 26 m span lattice girder in a large factory. Total length = 10 × 6 = 60 m. Weight = 60 × 16.5 = 990 kg (0.990 tonnes). At ₹62,000 per tonne (Ahmedabad, May 2026), material cost is approximately ₹61,380.
Related ISA Equal Angle Sections
Compare with adjacent sizes: ISA 100×100×12 (17.6 kg/m) · ISA 110×110×12 (19.5 kg/m). For all ISA equal angles see the Section Reference Library →
Frequently Asked Questions
What is the weight of ISA 110×110×10 per metre?
ISA 110×110×10 weighs 16.5 kg per metre as specified in IS 808:1989. For a standard 6-metre length, the total weight is 99.0 kg. For a 12-metre length, total weight is 198.0 kg.
ISA 110×110×10 ka weight per meter kitna hota hai?
IS 808:1989 standard ke according, ISA 110×110×10 ka weight 16.5 kg/m hota hai. 6 metre ki ek length ka total weight 99 kg hoga. Zyada accurate calculation ke liye upar diya gaya calculator use karein.
What are the dimensions of ISA 110×110×10?
ISA 110×110×10 per IS 808:1989 has a leg length of 110 mm, thickness of 10 mm, and root radius of 12.0 mm. The cross-sectional area is 20.99 cm².
