20×20×2 SHS Weight, Dimensions and IS 4923 Properties
20×20×2 SHS weighs 1.13 kg per metre as per IS 4923:1997.
- One 6-metre length weighs 6.78 kg · one 12-metre length weighs 13.56 kg
- 20 × 20 mm square section · wall thickness 2.0 mm
- Cross-sectional area 1.44 cm² · Ixx = 0.49 cm⁴
The 20×20×2 mm SHS is the smallest standard square hollow section in IS 4923:1997. At 1.13 kg/m it is used for light furniture frames, handrail infill sections, decorative grille panels, and minor fixtures where a small square tube is needed. Manufactured by Tata Structura, APL Apollo, and general tube mills in YST 210 and YST 240 grade.
20×20×2 SHS Weight Calculator
Enter the total length in metres to calculate weight.
20×20×2 SHS — Weight Calculator
IS 4923:1997 Dimensions and Sectional Properties
| Property | Symbol | Unit | Value |
|---|---|---|---|
| Outside dimension | B | mm | 20 |
| Wall thickness | t | mm | 2.0 |
| Cross-sectional area | A | cm² | 1.44 |
| Mass per metre | — | kg/m | 1.13 |
| Moment of inertia | Ixx = Iyy | cm⁴ | 0.49 |
| Elastic section modulus | Zxx = Zyy | cm³ | 0.49 |
| Radius of gyration | rxx = ryy | cm | 0.58 |
Outside dimensions and wall thickness as per IS 4923:1997. Cross-sectional area and mass per metre from IS 4923:1997 Table 2. Sectional properties calculated from IS 4923 geometry. SHS is doubly symmetric — Ixx = Iyy, Zxx = Zyy, rxx = ryy. Mass tolerance: ±6% per individual piece as per IS 4923:1997 Clause 10.
Common Applications of 20×20×2 SHS
The 20×20×2 SHS is used wherever a small, neat square tube is required: furniture legs and frames, gate infill balusters, decorative grille panels, light brackets, and display stand structures. Its 20 mm outside dimension fits standard slot-in fittings and corner connectors used in modular furniture. APL Apollo and Tata Structura supply this size in YST 210 and YST 240 grade from stock at most steel service centres.
Worked Example
A fabricator in Pune is making 40 chair frames, each requiring four legs of 20×20×2 SHS cut to 420 mm. Total length = 40 × 4 × 0.42 = 67.2 m. Weight = 67.2 × 1.13 = 75.9 kg. At a market rate of ₹72,000 per tonne (May 2026), the material cost is approximately ₹5,468 before fabrication.
Related IS 4923 Sections
20×20×2 SHS is the smallest standard SHS in IS 4923:1997. Next larger: 25×25×2 SHS (1.44 kg/m). For all hollow sections see the Section Reference Library →
Frequently Asked Questions
What is the weight of 20×20×2 SHS per metre?
20×20×2 SHS weighs 1.13 kg per metre as per IS 4923:1997. For a standard 6-metre length, the total weight is 6.78 kg. For a 12-metre length, total weight is 13.56 kg.
20×20×2 square hollow section ka weight kitna hota hai?
IS 4923:1997 ke according, 20×20×2 square hollow section ka weight 1.13 kg/m hota hai. 6 metre ki ek length ka total weight 6.78 kg hoga. Zyada accurate calculation ke liye upar diya gaya calculator use karein.
What are the dimensions and wall thickness of 20×20×2 SHS?
20×20×2 SHS per IS 4923:1997 has an outside dimension of 20 × 20 mm and a wall thickness of 2.0 mm. The cross-sectional area is 1.44 cm². Mass tolerance is ±6% per piece as per IS 4923:1997 Clause 10.
