Vizag Steel (RINL) Weight Chart — TMT, Angles, Channels and Beams
Vizag Steel (RINL) produces TMT bars, angles, channels, and beams at its Visakhapatnam integrated steel plant — all conforming to relevant BIS standards.
- TMT bars follow the D²/162 formula per IS:1786:2008 — a 16 mm bar weighs 1.58 kg/m
- Structural sections (angles, channels, beams) conform to IS:808:1989 for dimensions and mass
- RINL is a Government of India enterprise — mill test certificates carry PSU credibility for government infrastructure projects
Vizag Steel weight chart — covering the full RINL product range from 8 mm TMT bars to ISMB 600 beams — has been one of the harder reference pages to find online. RINL's own site distributes this data across multiple PDFs that are poorly indexed and mobile-hostile. This page consolidates the four main product categories into clean, searchable tables with IS-standard citations.
About Vizag Steel (RINL)
Rashtriya Ispat Nigam Ltd. (RINL), marketed as Vizag Steel, is a government-owned integrated steel producer located in Visakhapatnam, Andhra Pradesh. It is one of the few Indian steel plants with a shore-based location, enabling direct ore imports by ship. RINL produces a broad range of long steel products — TMT rebars, wire rods, structural sections, and rounds — primarily for the construction and infrastructure sectors. Its Fe 500D and Fe 550D TMT bars carry BIS certification and are specified on government infrastructure projects across South and Central India.
For procurement purposes, Vizag Steel ka weight chart below uses the same IS-standard formulas as any other BIS-certified producer. The weight per metre is a function of section geometry, not the brand — so these values apply directly to any conforming Vizag Steel product.
TMT Bar Weight Formula
Formula: Weight (kg/m) = D² / 162
- D
- Nominal diameter of the TMT bar, in millimetres
- 162
- Derived constant — from π × ρ_steel / 4, with steel density 7850 kg/m³ and unit conversions, per IS:1786:2008
Vizag Steel TMT Bar Weight Chart (IS:1786)
| Diameter (mm) | Weight (kg/m) | Pieces per MT (12 m lengths) |
|---|---|---|
| 8 | 0.395 | 211 |
| 10 | 0.617 | 135 |
| 12 | 0.888 | 94 |
| 16 | 1.580 | 53 |
| 20 | 2.469 | 34 |
| 25 | 3.858 | 22 |
| 28 | 4.834 | 17 |
| 32 | 6.313 | 13 |
Weight calculated using D²/162 per IS:1786:2008. Tolerance on mass: ±7% for bars up to 10 mm; ±5% for bars 10 mm and above per IS:1786:2008 Clause 8. Standard length 12 m; pieces per MT calculated at nominal weight.
Vizag Steel MS Angle Weight Chart (IS:808)
| Section (mm×mm×mm) | Weight (kg/m) |
|---|---|
| ISA 25×25×3 | 1.11 |
| ISA 40×40×4 | 2.42 |
| ISA 50×50×5 | 3.77 |
| ISA 65×65×6 | 5.80 |
| ISA 75×75×6 | 6.84 |
| ISA 90×90×8 | 10.80 |
| ISA 100×100×8 | 12.10 |
| ISA 100×100×10 | 14.90 |
| ISA 130×130×10 | 19.70 |
| ISA 150×150×12 | 27.30 |
Section dimensions and weights per IS:808:1989. Tolerance on mass: ±2.5% per IS:808. Equal angle sections shown; unequal angle sections available — consult your RINL distributor for full range.
Vizag Steel ISMC Channel Weight Chart (IS:808)
| Designation | Depth (mm) | Flange Width (mm) | Weight (kg/m) |
|---|---|---|---|
| ISMC 75 | 75 | 40 | 6.80 |
| ISMC 100 | 100 | 50 | 9.56 |
| ISMC 125 | 125 | 65 | 13.10 |
| ISMC 150 | 150 | 75 | 16.40 |
| ISMC 175 | 175 | 75 | 19.10 |
| ISMC 200 | 200 | 75 | 22.10 |
| ISMC 250 | 250 | 80 | 30.40 |
| ISMC 300 | 300 | 90 | 36.30 |
| ISMC 400 | 400 | 100 | 50.10 |
Section dimensions and weights per IS:808:1989 Table 3. Tolerance on mass: ±2.5%. For a full ISMC weight reference, see our ISMC channel weight chart.
Vizag Steel ISMB Beam Weight Chart (IS:808)
| Designation | Depth (mm) | Flange Width (mm) | Weight (kg/m) |
|---|---|---|---|
| ISMB 100 | 100 | 75 | 8.90 |
| ISMB 125 | 125 | 75 | 13.00 |
| ISMB 150 | 150 | 80 | 14.90 |
| ISMB 175 | 175 | 90 | 19.50 |
| ISMB 200 | 200 | 100 | 25.40 |
| ISMB 250 | 250 | 125 | 37.30 |
| ISMB 300 | 300 | 140 | 46.10 |
| ISMB 350 | 350 | 140 | 52.40 |
| ISMB 400 | 400 | 140 | 61.60 |
| ISMB 450 | 450 | 150 | 72.40 |
| ISMB 500 | 500 | 180 | 86.90 |
| ISMB 600 | 600 | 210 | 122.60 |
Section dimensions and weights per IS:808:1989 Table 1. Tolerance on mass: ±2.5%. RINL produces ISMB sections up to ISMB 600 at the Visakhapatnam plant.
Worked Example — Column Reinforcement with Vizag Steel Fe 500D
A civil contractor in Hyderabad is reinforcing columns for a four-storey residential building. The structural drawing specifies Vizag Steel Fe 500D, 16 mm diameter TMT bars. He needs to order 200 bars of 12 m length and confirm the total tonnage for procurement.
Step 1 — Calculate weight per metre:
Weight = D² / 162 = 16² / 162 = 256 / 162 = 1.58 kg/m
Step 2 — Calculate weight per bar:
Weight per bar = 1.58 × 12 = 18.96 kg per bar
Step 3 — Calculate total order weight:
Total = 200 × 18.96 = 3,792 kg = 3.79 MT
Step 4 — Plan logistics:
At 3.79 MT, the order requires a medium truck (Ashok Leyland 1615 or similar, rated 7.5 MT). The contractor confirms one trip is sufficient and requests the RINL mill test certificate for the Fe 500D grade to submit with the project quality records.
To calculate the weight of any other Vizag Steel TMT size or structural section instantly, use our free Metal Weight Calculator — select the section type, enter the dimensions, and get the kg/m result in seconds.
Frequently Asked Questions
What is the weight of Vizag Steel TMT bar per metre?
Vizag Steel TMT bar weight per metre is calculated using D²/162 per IS:1786:2008. Common values: 8 mm = 0.395 kg/m, 12 mm = 0.888 kg/m, 16 mm = 1.580 kg/m, 20 mm = 2.469 kg/m, 25 mm = 3.858 kg/m. These values apply to all Fe 500, Fe 500D, and Fe 550D grades from RINL.
Is Vizag Steel the same as RINL?
Yes. Vizag Steel is the trade name for Rashtriya Ispat Nigam Ltd. (RINL), a Government of India enterprise headquartered in Visakhapatnam, Andhra Pradesh. RINL operates the Visakhapatnam Steel Plant, commonly called the Vizag Steel Plant. When ordering from distributors, both names refer to the same mill and the same BIS-certified product.
Vizag Steel ka TMT bar ka weight kya hai?
Vizag Steel TMT bar ka weight formula se nikalta hai: D²/162 kg/m. For example, 16 mm bar ka weight = 256/162 = 1.58 kg/m. 12 m ki ek rod ka weight hoga 1.58 × 12 = 18.96 kg. Yeh value IS:1786:2008 ke anusar hai aur sabhi BIS-certified RINL grades pe apply hoti hai.
Which grades of TMT bar does Vizag Steel produce?
RINL (Vizag Steel) produces TMT bars in Fe 415, Fe 500, Fe 500D, and Fe 550D grades, all conforming to IS:1786:2008. The Fe 500D grade is recommended for seismic-resistant construction due to its superior ductility requirements — minimum 16% elongation versus 12% for Fe 500. RINL also produces Fe 600 grade for specialised structural applications.
What is the weight of ISMB 200 per metre?
ISMB 200 weighs 25.40 kg/m per IS:808:1989. The section has a depth of 200 mm, a flange width of 100 mm, and a web thickness of 5.7 mm. Vizag Steel produces ISMB sections from ISMB 100 to ISMB 600 at its Visakhapatnam plant, all conforming to IS:808:1989 dimensional and mass tolerances.
