ISA 130×130×12 Weight, Dimensions and IS 808 Properties
ISA 130×130×12 weighs 23.4 kg per metre as per IS 808:1989.
- One 6-metre length weighs 140.4 kg · one 12-metre length weighs 280.8 kg
- Leg 130 mm × thickness 12 mm · root radius 13.0 mm
- Cross-sectional area 29.78 cm² · Iuu = 430.0 cm⁴
ISA 130×130×12 is the heavier 130 mm equal-leg angle in IS 808:1989. At 23.4 kg/m it provides 19% more cross-sectional area than ISA 130×130×10, used for heavily loaded primary chord members and compound column sections in large heavy industrial structures.
ISA 130×130×12 Weight Calculator
Enter the total length in metres to calculate weight.
ISA 130×130×12 — Weight Calculator
IS 808:1989 Dimensions and Sectional Properties
| Property | Symbol | Unit | Value |
|---|---|---|---|
| Leg length | A | mm | 130 |
| Thickness | t | mm | 12 |
| Root radius | r1 | mm | 13.0 |
| Cross-sectional area | A | cm² | 29.78 |
| Mass per metre | — | kg/m | 23.4 |
| Centroid distance (Cxx = Cyy) | Cxx | cm | 3.18 |
| Moment of inertia (u–u, max) | Iuu | cm⁴ | 430.0 |
| Moment of inertia (v–v, min) | Ivv | cm⁴ | 111.6 |
| Elastic section modulus (u–u) | Zuu | cm³ | 47.78 |
| Radius of gyration (u–u) | ruu | cm | 3.8 |
| Radius of gyration (v–v) | rvv | cm | 1.94 |
Dimensions and properties as per IS 808:1989 (Reaffirmed 2001). Mass tolerance: ±3% per piece as per IS 808. u–u is the major principal axis at 45° to both legs; v–v is the minor principal axis. Zvv is not published in IS 808:1989 for angle sections.
Common Applications of ISA 130×130×12
ISA 130×130×12 is used for heavily loaded primary truss chord members in large industrial buildings, back-to-back compound column sections under very high axial load, primary heavy wind bracing, and large bolted connections at major structural joints. Available from JSPL and Tata Steel.
Worked Example
A structural engineer in Delhi specifies ISA 130×130×12 for 8 primary chord members, each 6 m long, for a heavily loaded 32 m span truss in a steel processing plant. Total length = 8 × 6 = 48 m. Weight = 48 × 23.4 = 1,123.2 kg (1.123 tonnes). At ₹62,000 per tonne (Delhi, May 2026), material cost is approximately ₹69,638.
Related ISA Equal Angle Sections
Compare with adjacent sizes: ISA 130×130×10 (19.6 kg/m) · ISA 150×150×10 (22.8 kg/m). For all ISA equal angles see the Section Reference Library →
Frequently Asked Questions
What is the weight of ISA 130×130×12 per metre?
ISA 130×130×12 weighs 23.4 kg per metre as specified in IS 808:1989. For a standard 6-metre length, the total weight is 140.4 kg. For a 12-metre length, total weight is 280.8 kg.
ISA 130×130×12 ka weight per meter kitna hota hai?
IS 808:1989 standard ke according, ISA 130×130×12 ka weight 23.4 kg/m hota hai. 6 metre ki ek length ka total weight 140.4 kg hoga. Zyada accurate calculation ke liye upar diya gaya calculator use karein.
What are the dimensions of ISA 130×130×12?
ISA 130×130×12 per IS 808:1989 has a leg length of 130 mm, thickness of 12 mm, and root radius of 13.0 mm. The cross-sectional area is 29.78 cm².
