50×25×2.5 RHS Weight, Dimensions and IS 4923 Properties
50×25×2.5 RHS weighs 2.67 kg per metre as per IS 4923:1997.
- One 6-metre length weighs 16.02 kg · one 12-metre length weighs 32.04 kg
- 50 × 25 mm rectangular section · wall thickness 2.5 mm
- Cross-sectional area 3.4 cm² · Ixx = 4.09 cm⁴ · Iyy = 11.91 cm⁴
50×25×2.5 RHS is a standard rectangular hollow section manufactured to IS 4923:1997 by APL Apollo. At 2.67 kg/m it is used for light handrail and shelf framing and similar structural applications where higher stiffness is required about the major axis.
50×25×2.5 RHS Weight Calculator
Enter the total length in metres to calculate weight.
50×25×2.5 RHS — Weight Calculator
IS 4923:1997 Dimensions and Sectional Properties
| Property | Symbol | Unit | Value |
|---|---|---|---|
| Outside width | B | mm | 50 |
| Outside height | H | mm | 25 |
| Wall thickness | t | mm | 2.5 |
| Cross-sectional area | A | cm² | 3.4 |
| Mass per metre | — | kg/m | 2.67 |
| Moment of inertia (x–x, about height axis) | Ixx | cm⁴ | 4.09 |
| Moment of inertia (y–y, about width axis) | Iyy | cm⁴ | 11.91 |
| Elastic section modulus (x–x) | Zxx | cm³ | 3.27 |
| Elastic section modulus (y–y) | Zyy | cm³ | 4.76 |
| Radius of gyration (x–x) | rxx | cm | 1.1 |
| Radius of gyration (y–y) | ryy | cm | 1.87 |
Outside dimensions and wall thickness as per IS 4923:1997. Cross-sectional area and mass per metre from IS 4923:1997 Table 4. Sectional properties calculated from IS 4923 geometry. x–x axis is about the height (H) direction; y–y axis is about the width (B) direction. RHS is not doubly symmetric — Ixx ≠ Iyy. Mass tolerance: ±6% per individual piece as per IS 4923:1997 Clause 10.
Common Applications of 50×25×2.5 RHS
50×25×2.5 RHS is used in light handrail and shelf framing and related structural framing. The rectangular hollow profile concentrates more material in the plane of bending, giving higher Iyy about the strong axis compared to an equal SHS. APL Apollo supply this section in YST 310 and YST 355 grade to IS 4923:1997 from stock at major steel distributors.
Worked Example
A fabricator in Chennai needs 20 handrail sections of 50×25×2.5 RHS, each 2.0 m long, for a light handrail and shelf framing. Total length = 20 × 2.0 = 40.0 m. Weight = 40.0 × 2.67 = 106.8 kg. At a market rate of ₹65,000 per tonne (May 2026), material cost is approximately ₹6,942 before cutting and fabrication.
Related IS 4923 Sections
50×25×2.5 RHS is the smallest standard RHS in IS 4923:1997. Next larger: 60×40×2.5 RHS (3.65 kg/m). For all hollow sections see the Section Reference Library →
Frequently Asked Questions
What is the weight of 50×25×2.5 RHS per metre?
50×25×2.5 RHS weighs 2.67 kg per metre as per IS 4923:1997. For a standard 6-metre length, the total weight is 16.02 kg. For a 12-metre length, total weight is 32.04 kg.
50×25×2.5 rectangular hollow section ka weight kitna hota hai?
IS 4923:1997 ke according, 50×25×2.5 rectangular hollow section ka weight 2.67 kg/m hota hai. 6 metre ki ek length ka total weight 16.02 kg hoga. Zyada accurate calculation ke liye upar diya gaya calculator use karein.
What are the dimensions and wall thickness of 50×25×2.5 RHS?
50×25×2.5 RHS per IS 4923:1997 has an outside width of 50 mm, outside height of 25 mm, and a wall thickness of 2.5 mm. The cross-sectional area is 3.4 cm². Mass tolerance is ±6% per piece as per IS 4923:1997 Clause 10.
