ISA 65×65×6 Weight, Dimensions and IS 808 Properties
ISA 65×65×6 weighs 5.9 kg per metre as per IS 808:1989.
- One 6-metre length weighs 35.4 kg · one 12-metre length weighs 70.8 kg
- Leg 65 mm × thickness 6 mm · root radius 8.0 mm
- Cross-sectional area 7.51 cm² · Iuu = 27.2 cm⁴
ISA 65×65×6 is a structural equal-leg angle in IS 808:1989. At 5.9 kg/m with a 65 mm leg it is used for truss chord members, back-to-back built-up struts, and bracing in light to medium industrial construction across India.
ISA 65×65×6 Weight Calculator
Enter the total length in metres to calculate weight.
ISA 65×65×6 — Weight Calculator
IS 808:1989 Dimensions and Sectional Properties
| Property | Symbol | Unit | Value |
|---|---|---|---|
| Leg length | A | mm | 65 |
| Thickness | t | mm | 6 |
| Root radius | r1 | mm | 8.0 |
| Cross-sectional area | A | cm² | 7.51 |
| Mass per metre | — | kg/m | 5.9 |
| Centroid distance (Cxx = Cyy) | Cxx | cm | 1.57 |
| Moment of inertia (u–u, max) | Iuu | cm⁴ | 27.2 |
| Moment of inertia (v–v, min) | Ivv | cm⁴ | 7.08 |
| Elastic section modulus (u–u) | Zuu | cm³ | 5.94 |
| Radius of gyration (u–u) | ruu | cm | 1.9 |
| Radius of gyration (v–v) | rvv | cm | 0.97 |
Dimensions and properties as per IS 808:1989 (Reaffirmed 2001). Mass tolerance: ±3% per piece as per IS 808. u–u is the major principal axis at 45° to both legs; v–v is the minor principal axis. Zvv is not published in IS 808:1989 for angle sections.
Common Applications of ISA 65×65×6
ISA 65×65×6 is used for truss bottom chord members in 10–14 m span structures, back-to-back compound struts in braced bays, diagonal bracing members, secondary beam support brackets, and gusset plate connections. Widely stocked in IS 2062 E250 grade by JSPL, Tata Steel, and general merchants across India.
Worked Example
A structural fabricator in Vadodara needs 8 truss bottom chord members of ISA 65×65×6, each 6 m long, for a 12 m span roof truss. Total length = 8 × 6 = 48 m. Weight = 48 × 5.9 = 283.2 kg. At ₹62,000 per tonne (Vadodara, May 2026), material cost is approximately ₹17,558.
Related ISA Equal Angle Sections
Compare with adjacent sizes: ISA 60×60×6 (5.4 kg/m) · ISA 65×65×8 (7.7 kg/m). For all ISA equal angles see the Section Reference Library →
Frequently Asked Questions
What is the weight of ISA 65×65×6 per metre?
ISA 65×65×6 weighs 5.9 kg per metre as specified in IS 808:1989. For a standard 6-metre length, the total weight is 35.4 kg. For a 12-metre length, total weight is 70.8 kg.
ISA 65×65×6 ka weight per meter kitna hota hai?
IS 808:1989 standard ke according, ISA 65×65×6 ka weight 5.9 kg/m hota hai. 6 metre ki ek length ka total weight 35.4 kg hoga. Zyada accurate calculation ke liye upar diya gaya calculator use karein.
What are the dimensions of ISA 65×65×6?
ISA 65×65×6 per IS 808:1989 has a leg length of 65 mm, thickness of 6 mm, and root radius of 8.0 mm. The cross-sectional area is 7.51 cm².
