ISA 110×110×12 Weight, Dimensions and IS 808 Properties
ISA 110×110×12 weighs 19.5 kg per metre as per IS 808:1989.
- One 6-metre length weighs 117.0 kg · one 12-metre length weighs 234.0 kg
- Leg 110 mm × thickness 12 mm · root radius 12.0 mm
- Cross-sectional area 24.88 cm² · Iuu = 253.0 cm⁴
ISA 110×110×12 is the heavier 110 mm equal-leg angle in IS 808:1989. At 19.5 kg/m it is used for heavily loaded back-to-back compound chord members in large-span trusses and primary built-up column sections where the 10 mm variant is under-capacity.
ISA 110×110×12 Weight Calculator
Enter the total length in metres to calculate weight.
ISA 110×110×12 — Weight Calculator
IS 808:1989 Dimensions and Sectional Properties
| Property | Symbol | Unit | Value |
|---|---|---|---|
| Leg length | A | mm | 110 |
| Thickness | t | mm | 12 |
| Root radius | r1 | mm | 12.0 |
| Cross-sectional area | A | cm² | 24.88 |
| Mass per metre | — | kg/m | 19.5 |
| Centroid distance (Cxx = Cyy) | Cxx | cm | 2.77 |
| Moment of inertia (u–u, max) | Iuu | cm⁴ | 253.0 |
| Moment of inertia (v–v, min) | Ivv | cm⁴ | 65.63 |
| Elastic section modulus (u–u) | Zuu | cm³ | 33.1 |
| Radius of gyration (u–u) | ruu | cm | 3.19 |
| Radius of gyration (v–v) | rvv | cm | 1.62 |
Dimensions and properties as per IS 808:1989 (Reaffirmed 2001). Mass tolerance: ±3% per piece as per IS 808. u–u is the major principal axis at 45° to both legs; v–v is the minor principal axis. Zvv is not published in IS 808:1989 for angle sections.
Common Applications of ISA 110×110×12
ISA 110×110×12 is used for heavily loaded compound chord members in large industrial trusses, primary built-up column sections under very high axial load, heavy wind bracing members, and large gusset plate bolted connections. Available from JSPL, Tata Steel, and SAIL.
Worked Example
A structural fabricator in Surat needs ISA 110×110×12 for 8 heavily loaded bottom chord members, each 6 m long, for a 28 m span truss. Total length = 8 × 6 = 48 m. Weight = 48 × 19.5 = 936 kg (0.936 tonnes). At ₹62,000 per tonne (Surat, May 2026), material cost is approximately ₹58,032.
Related ISA Equal Angle Sections
Compare with adjacent sizes: ISA 110×110×10 (16.5 kg/m) · ISA 120×120×10 (18.1 kg/m). For all ISA equal angles see the Section Reference Library →
Frequently Asked Questions
What is the weight of ISA 110×110×12 per metre?
ISA 110×110×12 weighs 19.5 kg per metre as specified in IS 808:1989. For a standard 6-metre length, the total weight is 117.0 kg. For a 12-metre length, total weight is 234.0 kg.
ISA 110×110×12 ka weight per meter kitna hota hai?
IS 808:1989 standard ke according, ISA 110×110×12 ka weight 19.5 kg/m hota hai. 6 metre ki ek length ka total weight 117 kg hoga. Zyada accurate calculation ke liye upar diya gaya calculator use karein.
What are the dimensions of ISA 110×110×12?
ISA 110×110×12 per IS 808:1989 has a leg length of 110 mm, thickness of 12 mm, and root radius of 12.0 mm. The cross-sectional area is 24.88 cm².
