ISA 150×150×15 Weight, Dimensions and IS 808 Properties
ISA 150×150×15 weighs 33.5 kg per metre as per IS 808:1989.
- One 6-metre length weighs 201.0 kg · one 12-metre length weighs 402.0 kg
- Leg 150 mm × thickness 15 mm · root radius 16.0 mm
- Cross-sectional area 42.68 cm² · Iuu = 803.0 cm⁴
ISA 150×150×15 is the heaviest standard 150 mm equal-leg angle in IS 808:1989. At 33.5 kg/m it is used for the most heavily loaded primary structural members in large heavy industrial trusses and compound column sections where the thinner variants are under-capacity.
ISA 150×150×15 Weight Calculator
Enter the total length in metres to calculate weight.
ISA 150×150×15 — Weight Calculator
IS 808:1989 Dimensions and Sectional Properties
| Property | Symbol | Unit | Value |
|---|---|---|---|
| Leg length | A | mm | 150 |
| Thickness | t | mm | 15 |
| Root radius | r1 | mm | 16.0 |
| Cross-sectional area | A | cm² | 42.68 |
| Mass per metre | — | kg/m | 33.5 |
| Centroid distance (Cxx = Cyy) | Cxx | cm | 3.72 |
| Moment of inertia (u–u, max) | Iuu | cm⁴ | 803.0 |
| Moment of inertia (v–v, min) | Ivv | cm⁴ | 207.9 |
| Elastic section modulus (u–u) | Zuu | cm³ | 78.5 |
| Radius of gyration (u–u) | ruu | cm | 4.34 |
| Radius of gyration (v–v) | rvv | cm | 2.21 |
Dimensions and properties as per IS 808:1989 (Reaffirmed 2001). Mass tolerance: ±3% per piece as per IS 808. u–u is the major principal axis at 45° to both legs; v–v is the minor principal axis. Zvv is not published in IS 808:1989 for angle sections.
Common Applications of ISA 150×150×15
ISA 150×150×15 is used for the most heavily loaded primary chord members in large-span heavy trusses, compound column sections under maximum axial load in multi-storey industrial frames, primary heavy bracing under extreme lateral loads, and large bolted connection nodes. Available from JSPL and Tata Steel.
Worked Example
A structural engineer in Ahmedabad specifies ISA 150×150×15 for 6 primary chord members, each 6 m long, for a 42 m span heavy crane girder truss. Total length = 6 × 6 = 36 m. Weight = 36 × 33.5 = 1,206 kg (1.206 tonnes). At ₹62,000 per tonne (Ahmedabad, May 2026), material cost is approximately ₹74,772.
Related ISA Equal Angle Sections
Compare with adjacent sizes: ISA 150×150×12 (27.2 kg/m) · ISA 175×175×12 (31.9 kg/m). For all ISA equal angles see the Section Reference Library →
Frequently Asked Questions
What is the weight of ISA 150×150×15 per metre?
ISA 150×150×15 weighs 33.5 kg per metre as specified in IS 808:1989. For a standard 6-metre length, the total weight is 201.0 kg. For a 12-metre length, total weight is 402.0 kg.
ISA 150×150×15 ka weight per meter kitna hota hai?
IS 808:1989 standard ke according, ISA 150×150×15 ka weight 33.5 kg/m hota hai. 6 metre ki ek length ka total weight 201 kg hoga. Zyada accurate calculation ke liye upar diya gaya calculator use karein.
What are the dimensions of ISA 150×150×15?
ISA 150×150×15 per IS 808:1989 has a leg length of 150 mm, thickness of 15 mm, and root radius of 16.0 mm. The cross-sectional area is 42.68 cm².
