ISA 25×25×5 Weight, Dimensions and IS 808 Properties
ISA 25×25×5 weighs 1.8 kg per metre as per IS 808:1989.
- One 6-metre length weighs 10.8 kg · one 12-metre length weighs 21.6 kg
- Leg 25 mm × thickness 5 mm · root radius 3.5 mm
- Cross-sectional area 2.26 cm² · Iuu = 1.1 cm⁴
ISA 25×25×5 is the heavier variant of the 25 mm equal-leg angle in IS 808:1989. At 1.8 kg/m it offers greater resistance than ISA 25×25×3 for the same leg size, making it suitable for stressed cleats and fixing brackets in light structural applications.
ISA 25×25×5 Weight Calculator
Enter the total length in metres to calculate weight.
ISA 25×25×5 — Weight Calculator
IS 808:1989 Dimensions and Sectional Properties
| Property | Symbol | Unit | Value |
|---|---|---|---|
| Leg length | A | mm | 25 |
| Thickness | t | mm | 5 |
| Root radius | r1 | mm | 3.5 |
| Cross-sectional area | A | cm² | 2.26 |
| Mass per metre | — | kg/m | 1.8 |
| Centroid distance (Cxx = Cyy) | Cxx | cm | 0.75 |
| Moment of inertia (u–u, max) | Iuu | cm⁴ | 1.1 |
| Moment of inertia (v–v, min) | Ivv | cm⁴ | 0.29 |
| Elastic section modulus (u–u) | Zuu | cm³ | 0.67 |
| Radius of gyration (u–u) | ruu | cm | 0.7 |
| Radius of gyration (v–v) | rvv | cm | 0.36 |
Dimensions and properties as per IS 808:1989 (Reaffirmed 2001). Mass tolerance: ±3% per piece as per IS 808. u–u is the major principal axis at 45° to both legs; v–v is the minor principal axis. Zvv is not published in IS 808:1989 for angle sections.
Common Applications of ISA 25×25×5
ISA 25×25×5 is used for stressed fixing cleats, gusset plate edge stiffeners, equipment base frame connections, and light secondary bracing where the 3 mm variant is under-strength. Commonly stocked at general steel merchants across India.
Worked Example
A machine fabricator in Pune needs 80 equipment mounting cleats of ISA 25×25×5, each 120 mm long. Total length = 80 × 0.12 = 9.6 m. Weight = 9.6 × 1.8 = 17.3 kg. At ₹65,000 per tonne (Pune, May 2026), material cost is approximately ₹1,123.
Related ISA Equal Angle Sections
Compare with adjacent sizes: ISA 25×25×3 (1.1 kg/m) · ISA 30×30×3 (1.4 kg/m). For all ISA equal angles see the Section Reference Library →
Frequently Asked Questions
What is the weight of ISA 25×25×5 per metre?
ISA 25×25×5 weighs 1.8 kg per metre as specified in IS 808:1989. For a standard 6-metre length, the total weight is 10.8 kg. For a 12-metre length, total weight is 21.6 kg.
ISA 25×25×5 ka weight per meter kitna hota hai?
IS 808:1989 standard ke according, ISA 25×25×5 ka weight 1.8 kg/m hota hai. 6 metre ki ek length ka total weight 10.8 kg hoga. Zyada accurate calculation ke liye upar diya gaya calculator use karein.
What are the dimensions of ISA 25×25×5?
ISA 25×25×5 per IS 808:1989 has a leg length of 25 mm, thickness of 5 mm, and root radius of 3.5 mm. The cross-sectional area is 2.26 cm².
