32×32×2 SHS Weight, Dimensions and IS 4923 Properties

By MetalWeightPro Team · Updated May 2026

32×32×2 SHS — 32 × 32 mm square hollow section, 2.0 mm wall, 1.89 kg/m, manufactured to IS 4923:1997. Supplied by APL Apollo and Tata Structura.

32×32×2 SHS weighs 1.89 kg per metre as per IS 4923:1997.

One 6-metre length weighs 11.34 kg · one 12-metre length weighs 22.68 kg
32 × 32 mm square section · wall thickness 2.0 mm
Cross-sectional area 2.4 cm² · I_xx = 2.25 cm⁴

32×32×2 SHS is a standard square hollow section manufactured to IS 4923:1997 by APL Apollo and Tata Structura. At 1.89 kg/m it is used for shelf frame and similar structural applications where a square hollow profile with defined sectional properties is required.

32×32×2 SHS Weight Calculator

Enter the total length in metres to calculate weight.

32×32×2 SHS — Weight Calculator

Length metres

Total weight —

In tonnes —

IS 4923:1997 Dimensions and Sectional Properties

Property	Symbol	Unit	Value
Outside dimension	B	mm	32
Wall thickness	t	mm	2.0
Cross-sectional area	A	cm²	2.4
Mass per metre	—	kg/m	1.89
Moment of inertia	I_xx = I_yy	cm⁴	2.25
Elastic section modulus	Z_xx = Z_yy	cm³	1.41
Radius of gyration	r_xx = r_yy	cm	0.97

Outside dimensions and wall thickness as per IS 4923:1997. Cross-sectional area and mass per metre from IS 4923:1997 Table 2. Sectional properties calculated from IS 4923 geometry. SHS is doubly symmetric — I_xx = I_yy, Z_xx = Z_yy, r_xx = r_yy. Mass tolerance: ±6% per individual piece as per IS 4923:1997 Clause 10.

32×32×2 SHS cross-section diagram showing 32 mm outside dimension and 2.0 mm wall per IS 4923:1997 — 32×32×2 SHS per IS 4923:1997. B = 32 mm · t = 2.0 mm · A = 2.4 cm² · I_xx = 2.25 cm⁴.

Common Applications of 32×32×2 SHS

32×32×2 SHS is used in shelf frame and related structural framing. The square hollow profile provides equal stiffness about both axes, making it well suited for columns, posts, and members loaded in biaxial bending. APL Apollo and Tata Structura supply this section in YST 310 and YST 355 grade to IS 4923:1997 from stock at major steel distributors across India.

Worked Example

A fabricator in Nagpur needs 30 shelving bracketss of 32×32×2 SHS, each 1.2 m long, for a shelf frame. Total length = 30 × 1.2 = 36.0 m. Weight = 36.0 × 1.89 = 68.0 kg. At a market rate of ₹65,000 per tonne (May 2026), material cost is approximately ₹4,423 before cutting and fabrication.

Related IS 4923 Sections

Previous smaller: 25×25×2 SHS (1.44 kg/m) · Next larger: 40×40×2.5 SHS (2.87 kg/m). For all hollow sections see the Section Reference Library →

Frequently Asked Questions

What is the weight of 32×32×2 SHS per metre?

32×32×2 SHS weighs 1.89 kg per metre as per IS 4923:1997. For a standard 6-metre length, the total weight is 11.34 kg. For a 12-metre length, total weight is 22.68 kg.

32×32×2 square hollow section ka weight kitna hota hai?

IS 4923:1997 ke according, 32×32×2 square hollow section ka weight 1.89 kg/m hota hai. 6 metre ki ek length ka total weight 11.34 kg hoga. Zyada accurate calculation ke liye upar diya gaya calculator use karein.

What are the dimensions and wall thickness of 32×32×2 SHS?

32×32×2 SHS per IS 4923:1997 has an outside dimension of 32 × 32 mm and a wall thickness of 2.0 mm. The cross-sectional area is 2.4 cm². Mass tolerance is ±6% per piece as per IS 4923:1997 Clause 10.
