ISA 150×150×10 Weight, Dimensions and IS 808 Properties
ISA 150×150×10 weighs 22.8 kg per metre as per IS 808:1989.
- One 6-metre length weighs 136.8 kg · one 12-metre length weighs 273.6 kg
- Leg 150 mm × thickness 10 mm · root radius 16.0 mm
- Cross-sectional area 29.0 cm² · Iuu = 566.0 cm⁴
ISA 150×150×10 is a large heavy structural equal-leg angle in IS 808:1989. At 22.8 kg/m with a 150 mm leg it is used for primary chord members in heavy long-span trusses, back-to-back compound column legs in multi-storey industrial frames, and primary bracing in large plant structures.
ISA 150×150×10 Weight Calculator
Enter the total length in metres to calculate weight.
ISA 150×150×10 — Weight Calculator
IS 808:1989 Dimensions and Sectional Properties
| Property | Symbol | Unit | Value |
|---|---|---|---|
| Leg length | A | mm | 150 |
| Thickness | t | mm | 10 |
| Root radius | r1 | mm | 16.0 |
| Cross-sectional area | A | cm² | 29.0 |
| Mass per metre | — | kg/m | 22.8 |
| Centroid distance (Cxx = Cyy) | Cxx | cm | 3.46 |
| Moment of inertia (u–u, max) | Iuu | cm⁴ | 566.0 |
| Moment of inertia (v–v, min) | Ivv | cm⁴ | 147.1 |
| Elastic section modulus (u–u) | Zuu | cm³ | 53.72 |
| Radius of gyration (u–u) | ruu | cm | 4.42 |
| Radius of gyration (v–v) | rvv | cm | 2.25 |
Dimensions and properties as per IS 808:1989 (Reaffirmed 2001). Mass tolerance: ±3% per piece as per IS 808. u–u is the major principal axis at 45° to both legs; v–v is the minor principal axis. Zvv is not published in IS 808:1989 for angle sections.
Common Applications of ISA 150×150×10
ISA 150×150×10 is used for primary chord members in 30–40 m span heavy industrial trusses, back-to-back compound column sections in steel-framed multi-storey industrial buildings, primary heavy wind bracing, and large bolted connection joints. Stocked by JSPL and Tata Steel in IS 2062 E250 grade.
Worked Example
A structural engineer in Mumbai specifies ISA 150×150×10 for 10 primary chord members, each 6 m long, for a 36 m span crane gantry truss. Total length = 10 × 6 = 60 m. Weight = 60 × 22.8 = 1,368 kg (1.368 tonnes). At ₹62,000 per tonne (Mumbai, May 2026), material cost is approximately ₹84,816.
Related ISA Equal Angle Sections
Compare with adjacent sizes: ISA 130×130×12 (23.4 kg/m) · ISA 150×150×12 (27.2 kg/m). For all ISA equal angles see the Section Reference Library →
Frequently Asked Questions
What is the weight of ISA 150×150×10 per metre?
ISA 150×150×10 weighs 22.8 kg per metre as specified in IS 808:1989. For a standard 6-metre length, the total weight is 136.8 kg. For a 12-metre length, total weight is 273.6 kg.
ISA 150×150×10 ka weight per meter kitna hota hai?
IS 808:1989 standard ke according, ISA 150×150×10 ka weight 22.8 kg/m hota hai. 6 metre ki ek length ka total weight 136.8 kg hoga. Zyada accurate calculation ke liye upar diya gaya calculator use karein.
What are the dimensions of ISA 150×150×10?
ISA 150×150×10 per IS 808:1989 has a leg length of 150 mm, thickness of 10 mm, and root radius of 16.0 mm. The cross-sectional area is 29.00 cm².
