ISA 50×50×6 Weight, Dimensions and IS 808 Properties
ISA 50×50×6 weighs 4.5 kg per metre as per IS 808:1989.
- One 6-metre length weighs 27.0 kg · one 12-metre length weighs 54.0 kg
- Leg 50 mm × thickness 6 mm · root radius 7.0 mm
- Cross-sectional area 5.69 cm² · Iuu = 11.9 cm⁴
ISA 50×50×6 is the heavier 50 mm equal-leg angle in IS 808:1989. At 4.5 kg/m it provides 18.5% more cross-sectional area than ISA 50×50×5, used where higher axial capacity is required in truss members and bracing without increasing leg size.
ISA 50×50×6 Weight Calculator
Enter the total length in metres to calculate weight.
ISA 50×50×6 — Weight Calculator
IS 808:1989 Dimensions and Sectional Properties
| Property | Symbol | Unit | Value |
|---|---|---|---|
| Leg length | A | mm | 50 |
| Thickness | t | mm | 6 |
| Root radius | r1 | mm | 7.0 |
| Cross-sectional area | A | cm² | 5.69 |
| Mass per metre | — | kg/m | 4.5 |
| Centroid distance (Cxx = Cyy) | Cxx | cm | 1.28 |
| Moment of inertia (u–u, max) | Iuu | cm⁴ | 11.9 |
| Moment of inertia (v–v, min) | Ivv | cm⁴ | 3.1 |
| Elastic section modulus (u–u) | Zuu | cm³ | 3.4 |
| Radius of gyration (u–u) | ruu | cm | 1.45 |
| Radius of gyration (v–v) | rvv | cm | 0.74 |
Dimensions and properties as per IS 808:1989 (Reaffirmed 2001). Mass tolerance: ±3% per piece as per IS 808. u–u is the major principal axis at 45° to both legs; v–v is the minor principal axis. Zvv is not published in IS 808:1989 for angle sections.
Common Applications of ISA 50×50×6
ISA 50×50×6 is used for loaded truss web and chord members, back-to-back compound struts under higher compression, bracing members in medium-span structures, and bolted connection cleats requiring greater bearing capacity. Stocked by JSPL, Tata Steel, and RINL.
Worked Example
A fabricator in Chennai needs 20 compression web members of ISA 50×50×6, each 1.8 m long, for a 12 m span Pratt truss. Total length = 20 × 1.8 = 36 m. Weight = 36 × 4.5 = 162 kg. At ₹62,000 per tonne (Chennai, May 2026), material cost is approximately ₹10,044.
Related ISA Equal Angle Sections
Compare with adjacent sizes: ISA 50×50×5 (3.8 kg/m) · ISA 55×55×6 (4.9 kg/m). For all ISA equal angles see the Section Reference Library →
Frequently Asked Questions
What is the weight of ISA 50×50×6 per metre?
ISA 50×50×6 weighs 4.5 kg per metre as specified in IS 808:1989. For a standard 6-metre length, the total weight is 27.0 kg. For a 12-metre length, total weight is 54.0 kg.
ISA 50×50×6 ka weight per meter kitna hota hai?
IS 808:1989 standard ke according, ISA 50×50×6 ka weight 4.5 kg/m hota hai. 6 metre ki ek length ka total weight 27 kg hoga. Zyada accurate calculation ke liye upar diya gaya calculator use karein.
What are the dimensions of ISA 50×50×6?
ISA 50×50×6 per IS 808:1989 has a leg length of 50 mm, thickness of 6 mm, and root radius of 7.0 mm. The cross-sectional area is 5.69 cm².
