ISA 75×75×10 Weight, Dimensions and IS 808 Properties
ISA 75×75×10 weighs 10.9 kg per metre as per IS 808:1989.
- One 6-metre length weighs 65.4 kg · one 12-metre length weighs 130.8 kg
- Leg 75 mm × thickness 10 mm · root radius 9.0 mm
- Cross-sectional area 13.94 cm² · Iuu = 64.5 cm⁴
ISA 75×75×10 is the heaviest standard variant of the 75 mm equal-leg angle in IS 808:1989. At 10.9 kg/m it is used for heavily loaded truss chord members, built-up section compound struts under significant axial compression, and primary structural members in medium industrial buildings.
ISA 75×75×10 Weight Calculator
Enter the total length in metres to calculate weight.
ISA 75×75×10 — Weight Calculator
IS 808:1989 Dimensions and Sectional Properties
| Property | Symbol | Unit | Value |
|---|---|---|---|
| Leg length | A | mm | 75 |
| Thickness | t | mm | 10 |
| Root radius | r1 | mm | 9.0 |
| Cross-sectional area | A | cm² | 13.94 |
| Mass per metre | — | kg/m | 10.9 |
| Centroid distance (Cxx = Cyy) | Cxx | cm | 1.96 |
| Moment of inertia (u–u, max) | Iuu | cm⁴ | 64.5 |
| Moment of inertia (v–v, min) | Ivv | cm⁴ | 16.64 |
| Elastic section modulus (u–u) | Zuu | cm³ | 12.66 |
| Radius of gyration (u–u) | ruu | cm | 2.15 |
| Radius of gyration (v–v) | rvv | cm | 1.09 |
Dimensions and properties as per IS 808:1989 (Reaffirmed 2001). Mass tolerance: ±3% per piece as per IS 808. u–u is the major principal axis at 45° to both legs; v–v is the minor principal axis. Zvv is not published in IS 808:1989 for angle sections.
Common Applications of ISA 75×75×10
ISA 75×75×10 is used for heavily loaded back-to-back compound chord members in medium-span trusses, primary bracing members under high axial load, column lacings in compound column sections, and connections requiring maximum bearing area. Available from JSPL and Tata Steel.
Worked Example
A structural engineer in Delhi specifies ISA 75×75×10 for 12 truss chord members, each 6 m long, in a heavily loaded 18 m span truss. Total length = 12 × 6 = 72 m. Weight = 72 × 10.9 = 784.8 kg (0.785 tonnes). At ₹62,000 per tonne (Delhi, May 2026), material cost is approximately ₹48,658.
Related ISA Equal Angle Sections
Compare with adjacent sizes: ISA 75×75×8 (8.9 kg/m) · ISA 80×80×8 (9.6 kg/m). For all ISA equal angles see the Section Reference Library →
Frequently Asked Questions
What is the weight of ISA 75×75×10 per metre?
ISA 75×75×10 weighs 10.9 kg per metre as specified in IS 808:1989. For a standard 6-metre length, the total weight is 65.4 kg. For a 12-metre length, total weight is 130.8 kg.
ISA 75×75×10 ka weight per meter kitna hota hai?
IS 808:1989 standard ke according, ISA 75×75×10 ka weight 10.9 kg/m hota hai. 6 metre ki ek length ka total weight 65.4 kg hoga. Zyada accurate calculation ke liye upar diya gaya calculator use karein.
What are the dimensions of ISA 75×75×10?
ISA 75×75×10 per IS 808:1989 has a leg length of 75 mm, thickness of 10 mm, and root radius of 9.0 mm. The cross-sectional area is 13.94 cm².
