ISMC 225 Weight, Dimensions and IS 808 Properties
ISMC 225 weighs 25.4 kg per metre as per IS 808:1989.
- One 6-metre length weighs 152.4 kg · one 12-metre length weighs 304.8 kg
- Web height 225 mm · flange width 80 mm · web thickness 6.4 mm
- Cross-sectional area 32.30 cm² · Ixx = 2694.1 cm⁴
ISMC 225 is a medium-heavy channel in IS 808:1989. At 25.4 kg/m with a 225 mm web and 80 mm flange, it is less commonly stocked than ISMC 200 or ISMC 250 but is specified for intermediate spans where neither smaller nor larger standard sizes are efficient.
ISMC 225 Weight Calculator
Enter the total length in metres to calculate weight.
ISMC 225 — Weight Calculator
IS 808:1989 Dimensions and Sectional Properties
| Property | Symbol | Unit | Value |
|---|---|---|---|
| Web height | h | mm | 225 |
| Flange width | b | mm | 80 |
| Web thickness | tw | mm | 6.4 |
| Flange thickness | tf | mm | 10.2 |
| Cross-sectional area | A | cm² | 32.30 |
| Mass per metre | — | kg/m | 25.4 |
| Moment of inertia (x–x) | Ixx | cm⁴ | 2694.1 |
| Moment of inertia (y–y) | Iyy | cm⁴ | 117.8 |
| Elastic section modulus (x–x) | Zxx | cm³ | 239.5 |
| Elastic section modulus (y–y) | Zyy | cm³ | 20.5 |
| Radius of gyration (x–x) | rxx | cm | 9.13 |
| Radius of gyration (y–y) | ryy | cm | 1.91 |
Dimensions and properties as per IS 808:1989 (reaffirmed 2021). Mass tolerance: ±2.5% per piece per IS 808.
Common Applications of ISMC 225
ISMC 225 is used for intermediate floor beams, back-to-back channel columns in prefabricated industrial buildings, heavy stair stringers, and crane gantry runway channels in 3 to 5 tonne capacity applications. Because it is less commonly stocked than ISMC 200 and ISMC 250, lead times from distributors may be 3–5 days for non-stocked orders. SAIL and JSW Steel produce ISMC 225 in IS 2062 E250 grade.
Worked Example
A fabricator in Surat needs 10 crane gantry channels of ISMC 225, each 6 m long, for a 4-tonne EOT crane runway. Total length = 10 × 6 = 60 m. Weight = 60 × 25.4 = 1,524 kg (1.524 tonnes). At a market rate of ₹58,000 per tonne (Surat, May 2026), the material cost is approximately ₹88,390 before drilling and erection.
Related ISMC Sections
Compare with adjacent sizes: ISMC 200 (22.1 kg/m) · ISMC 250 (30.6 kg/m). For all ISMC sizes see the Section Reference Library →
Frequently Asked Questions
What is the weight of ISMC 225 per metre?
ISMC 225 weighs 25.4 kg per metre as specified in IS 808:1989. For a standard 6-metre length, the total weight is 152.4 kg. For a 12-metre length, total weight is 304.8 kg.
ISMC 225 ka weight per meter kitna hota hai?
IS 808:1989 standard ke according, ISMC 225 ka weight 25.4 kg/m hota hai. 6 metre ki ek length ka total weight 152.4 kg hoga. Zyada accurate calculation ke liye upar diya gaya calculator use karein.
What are the dimensions of ISMC 225?
ISMC 225 per IS 808:1989 has a web height of 225 mm, flange width of 80 mm, web thickness of 6.4 mm, and flange thickness of 10.2 mm. The cross-sectional area is 32.30 cm².
