ISA 60×60×6 Weight, Dimensions and IS 808 Properties
ISA 60×60×6 weighs 5.4 kg per metre as per IS 808:1989.
- One 6-metre length weighs 32.4 kg · one 12-metre length weighs 64.8 kg
- Leg 60 mm × thickness 6 mm · root radius 8.0 mm
- Cross-sectional area 6.91 cm² · Iuu = 21.2 cm⁴
ISA 60×60×6 is a standard structural equal-leg angle in IS 808:1989. At 5.4 kg/m with a 60 mm leg it is used for roof truss chord and web members, back-to-back compound struts, and diagonal bracing in light to medium industrial buildings.
ISA 60×60×6 Weight Calculator
Enter the total length in metres to calculate weight.
ISA 60×60×6 — Weight Calculator
IS 808:1989 Dimensions and Sectional Properties
| Property | Symbol | Unit | Value |
|---|---|---|---|
| Leg length | A | mm | 60 |
| Thickness | t | mm | 6 |
| Root radius | r1 | mm | 8.0 |
| Cross-sectional area | A | cm² | 6.91 |
| Mass per metre | — | kg/m | 5.4 |
| Centroid distance (Cxx = Cyy) | Cxx | cm | 1.47 |
| Moment of inertia (u–u, max) | Iuu | cm⁴ | 21.2 |
| Moment of inertia (v–v, min) | Ivv | cm⁴ | 5.51 |
| Elastic section modulus (u–u) | Zuu | cm³ | 4.99 |
| Radius of gyration (u–u) | ruu | cm | 1.75 |
| Radius of gyration (v–v) | rvv | cm | 0.89 |
Dimensions and properties as per IS 808:1989 (Reaffirmed 2001). Mass tolerance: ±3% per piece as per IS 808. u–u is the major principal axis at 45° to both legs; v–v is the minor principal axis. Zvv is not published in IS 808:1989 for angle sections.
Common Applications of ISA 60×60×6
ISA 60×60×6 is used for roof truss chord members in 8–12 m span structures, back-to-back compound column sections, diagonal bracing in multi-bay sheds, purlin cleat connections, and secondary beam brackets. Widely stocked by JSPL, Tata Steel, and RINL in IS 2062 E250 grade.
Worked Example
A structural fabricator in Bengaluru needs 14 bottom chord members of ISA 60×60×6, each 4 m long, for a 12 m span Howe truss. Total length = 14 × 4 = 56 m. Weight = 56 × 5.4 = 302.4 kg. At ₹62,000 per tonne (Bengaluru, May 2026), material cost is approximately ₹18,749.
Related ISA Equal Angle Sections
Compare with adjacent sizes: ISA 55×55×6 (4.9 kg/m) · ISA 65×65×6 (5.9 kg/m). For all ISA equal angles see the Section Reference Library →
Frequently Asked Questions
What is the weight of ISA 60×60×6 per metre?
ISA 60×60×6 weighs 5.4 kg per metre as specified in IS 808:1989. For a standard 6-metre length, the total weight is 32.4 kg. For a 12-metre length, total weight is 64.8 kg.
ISA 60×60×6 ka weight per meter kitna hota hai?
IS 808:1989 standard ke according, ISA 60×60×6 ka weight 5.4 kg/m hota hai. 6 metre ki ek length ka total weight 32.4 kg hoga. Zyada accurate calculation ke liye upar diya gaya calculator use karein.
What are the dimensions of ISA 60×60×6?
ISA 60×60×6 per IS 808:1989 has a leg length of 60 mm, thickness of 6 mm, and root radius of 8.0 mm. The cross-sectional area is 6.91 cm².
